| CARACTERÍSTICAS CONSTRUCTIVAS | |
|---|---|
| Cuerpo bomba | acero AISI 304 |
| Soporte del motor | aluminio |
| Rodete | noryl® o acero AISI 304 |
| Plato apoyo sello | noryl® |
| Sello | cerámica-grafito-NBR |
| Extremo eje bomba | acero AISI 416 |
| Temperatura ambiente | 0 – 50 °C |
| Guarniciones cuerpo bomba | máximo 8 bar |
| Motor | |
|---|---|
| Motor de inducción de 2 polos | 3~ 230/400V-50Hz 1~ 230V-50Hz |
| Clase de aislamiento | F |
| Grado de protección | IPX4 |
| MODEL 1~ | MODEL 3~ | HP | kW | FLOW RATE (l/min) |
H (m) |
|---|---|---|---|---|---|
| INOX 100N/60 | INOXT 100N/60 | 1 | 0.74 | 10 ÷ 63.3 | 42.3 ÷ 21 |
| INOX 100N/62 | INOXT 100N/62 | 1 | 0.74 | 10 ÷ 63.3 | 42.3 ÷ 21 |
| INOX 120/60 | INOXT 120/60 | 1.2 | 0.88 | 10 ÷ 63.3 | 47.4 ÷ 24.3 |
| INOX 120/62 | INOXT 120/62 | 1.2 | 0.88 | 10 ÷ 63.3 | 47.4 ÷ 24.3 |
| INOX 140/60 | INOXT 140/60 | 1.5 | 1.1 | 10 ÷ 63.3 | 53.6 ÷ 29 |
| INOX 140/62 | INOXT 140/62 | 1.5 | 1.1 | 10 ÷ 63.3 | 53.6 ÷ 29 |
| INOX 50/60 | INOXT 50/60 | 0.6 | 0.44 | 10 ÷ 50 | 33.1 ÷ 17.5 |
| INOX 80N/60 | INOXT 80N/60 | 0.8 | 0.59 | 10 ÷ 50 | 37.5 ÷ 21.5 |
