| CARACTERÍSTICAS CONSTRUCTIVAS | |
|---|---|
| Boca de impulsión | 1” 1/4 G |
| Camisa exterior, rodetes y difusores | acero AISI 304 |
| Tamiz del prefiltro | 2 mm |
| Paso de sólidos | máximo 20 m |
| Temperatura ambiente | +5 ÷ +40 °C |
| Temperatura del líquido | máximo 50 g/m³ |
| Cantidad de arena en el agua | H07 RNF, 20 m |
| Cable | máximo 20 |
| Número de arranques/hr | flotante |
| Motor | |
|---|---|
| Motor asíncrono de 2 polos | 3~ 380/415V-50Hz, 1~ 220/240V-50Hz con termoprotector |
| Clase de aislamiento | F |
| Grado de protección | IP68 |
| MODEL | HP | kW | FLOW RATE (l/min) |
H (m) |
|---|---|---|---|---|
| 5PES 3/4 G | 0.75 | 0.55 | 25 ÷ 75 | 40 ÷ 18 |
| 5PES 5/6 | 1.5 | 1.1 | 42 ÷ 125 | 58.5 ÷ 24 |
| 5PES 3/5 G | 1 | 0.75 | 25 ÷ 75 | 49 ÷ 22 |
| 5PES 3/6 G | 1 | 0.75 | 25 ÷ 75 | 58.5 ÷ 25 |
| 5PES 3/7 G | 1.2 | 0.9 | 25 ÷ 75 | 67 ÷ 28 |
| 5PES 3/8 G | 1.5 | 1.1 | 25 ÷ 75 | 75.5 ÷ 31 |
| 5PES 5/4 G | 1 | 0.75 | 42 ÷ 125 | 40.5 ÷ 18.5 |
| 5PES 5/5 G | 1.2 | 0.9 | 42 ÷ 125 | 50 ÷ 22 |
| 5PES 5/6 G | 1.5 | 1.1 | 42 ÷ 125 | 58.5 ÷ 24 |
| 5PES 3/4 | 0.75 | 0.55 | 25 ÷ 75 | 40 ÷ 18 |
| 5PES 3/5 | 1 | 0.75 | 25 ÷ 75 | 49 ÷ 22 |
| 5PES 3/6 | 1 | 0.75 | 25 ÷ 75 | 58.5 ÷ 25 |
| 5PES 3/7 | 1.2 | 0.9 | 25 ÷ 75 | 67 ÷ 28 |
| 5PES 3/8 | 1.5 | 1.1 | 25 ÷ 75 | 75.5 ÷ 31 |
| 5PES 5/4 | 1 | 0.75 | 42 ÷ 125 | 40.5 ÷ 18.5 |
| 5PES 5/5 | 1.2 | 0.9 | 42 ÷ 125 | 50 ÷ 22 |
